(Solved): The force F is applied at the end of arm ACD, which is mounted to a vertical post. Replace this sing ...
The force
Fis applied at the end of arm
ACD, which is mounted to a vertical post. Replace this single force
Fby an equivalent forcecouple system at
B. Next, redistribute this force and couple by replacing it with two forces acting in the same direction as
F, one at
Cand the other at
D, and determine the forces supported by the two hex-bolts. Use values of
F=565N,\theta =23\deg ,b=1.6m,d=0.25m,h
0.81m, and
I=2.55m. Part 1
